XDF-A PRECISION CERAMIC FOG NOZZLE





型　號 Part No.	孔　徑 Orifice Size	規　格 Specification
XDF-A008	0.08mm	Thread 10/24
XDF-A010	0.10mm	Thread 10/24
XDF-A012	0.12mm	Thread 10/24
XDF-A015	0.15mm	Thread 10/24
XDF-A02	0.20mm	Thread 10/24
XDF-A03	0.30mm	Thread 10/24
XDF-AK008	0.08mm	Thread 12/24
XDF-AK010	0.10mm	Thread 12/24
XDF-AK012	0.12mm	Thread 12/24
XDF-AK015	0.15mm	Thread 12/24
XDF-AK02	0.20mm	Thread 12/24
XDF-AK03	0.30mm	Thread 12/24
XDF-AK008	0.08mm	With filter,thread 1/8'' male
XDF-AK010	0.10mm	With filter,thread 1/8'' male
XDF-AK012	0.12mm	With filter,thread 1/8'' male
XDF-AK015	0.15mm	With filter,thread 1/8'' male
XDF-AK02	0.20mm	With filter,thread 1/8'' male
XDF-AK03	0.30mm	With filter,thread 1/8'' male

     1.The nickel-coating brass boby & grinding ceramic wafer.

     2.All type anti-drip adapters include stainless stell core & spring and viton O-ring & ball.

3.Operating pressure up to 1700psi(120kgf/cm2)

4.Easily installed and loosened by hand without the need for special tools.
